ENGINE
Honda 20 HP overhead valve, air cooled, 4-stroke power plant w/ electronic ignition, low oil shutdown, full pressure lubrication and integral fuel pump.
PHYSICAL
22″W x 30″L x 26″H – 420 lbs wet.
STARTING
Electric start w/ built-in 20A charging circuit.
CONTROLS
Console remotely mounted at right side pulling unit w/ valve bodies and hydraulic components inside protective stainless steel. Throttle and choke control w/ 12 GPM flow and adjustable system pressure relief – preset to 2250 PSI. Engine key switch labeled “Stop-Run-Start”. Two keys supplied.
PANEL
Stainless steel panel w/ engraved control indicators and lockable stainless cover.
FASTENERS
Stainless steel fasteners used exclusively.
FUEL TANK
2.5 Gallon CARB certified fuel tank.
PUMP
.81 cu. in. displacement, vertical mount pump w/ jaw-type coupling and shock absorbing rubber insert. Maximum output 2250 P.S.I. @ 12 GPM.
FILTRATION
Heavy duty spin on type 10 micron hydraulic oil filter. Tank suction strainer. Oil fill cap breather.
GAUGES
Pulling power gauge, hour meter and hydraulic oil filter back pressure gauge w/ green/yellow/red service indicator. 12VDC panel light.
TANK
18 Gallon aluminum reservoir w/ Almag cover and Citgo #32 Anti-Wear Premium hydraulic oil included.
OIL COOLER
Passive oil cooler installed on the side of the power source tank.
CONNECTION
Pressure and return lines routed with stainless steel tube to right front of power source panel. Dripless quick couples provided at pressure and return outlets.
COVER
Vinyl weatherproof cover included.
POWER SOURCE WARRANTY
One year full parts coverage.
