Pulling Unit

Constant speed, constant pull 19″ Almag horizontal capstan for multi-directional pulling. Automatic levelwind onto removable rope cassettes. Capstan and cassette mounted on hydraulically actuated tilting platform for pull angle alignment from -10 to 30 degrees. Counterbalance valve protection for cylinder retraction. Fully hydraulic, shift-on-the fly two speed provides 1500 lbs pull @ 188 fpm in high speed mode and 3000 lbs pull @ 94 fpm in high torque mode. Full feathering bi-directional valve provides for line pull and payout without levelwind compromise.

Pulling Unit can be found on the following products

Model 1570-B Puller
