ENGINE
Honda 13 HP overhead valve, air-cooled, 4-stroke power plant with electronic ignition, low oil shutdown, gravity fuel system and automatic decompression.
PHYSICAL
22″W x 30″L x 26″H – 340 lbs wet.
STARTING
Electric start with built-in 3A charging circuit. Recoil start included.
CONTROLS
Throttle control with choke. Adjustable system pressure relief, preset to 1500 or 2250 PSI depending on pump choice selected. Engine key switch labeled “Stop-Run-Start”. Two keys supplied.
PANEL
One-piece polymer panel with engraved control indicators.
FASTENERS
Stainless steel fasteners used exclusively.
FUEL TANK
Integral 2.2 quart poly tank provides 6.6 HP-Hours of use.
PUMP CHOICES
Vertical mount pump with jaw-type coupling and shock absorbing rubber insert. 43 cu-in displacement: 2250 PSI @ 6 GPM
FILTRATION
Heavy-duty spin on type 10 micron hydraulic oil filter. Tank suction strainer. Oil fill cap breather.
GAUGES
Oil level, temperature, and pressure gauges. Hydraulic oil filter back pressure gauge with green/yellow/red service indicator. 12VDC hour meter with panel lite.
TANK
18 Gallon aluminum treadplate reservoir with Almag lid. #32 Anti-Wear premium hydraulic oil included.
CONNECTION
Pressure and return lines routed with stainless steel tube to right front of power source panel. Dripless quick couples provided at pressure and return outlets.
COVER
Vinyl weatherproof cover included.
WARRANTY
One year full parts coverage.
