Image from right rear and above of a Sauber Model 4500 Pole Trailer with a Model 1632 Three Reel Frame including Model 1602 All Bronze Tensioning Brakes. Sauber Mfg. Co. Pole trailers include nylon slides and cat track wire management for simple, reliable extension and retraction. The trailer is shown in front of a red metal building on concrete.

Close image from right of a Sauber Mfg. Co. Model 4500 Pole Trailer with a Model 1632 Three Reel Frame including Model 1602 All Bronze Tensioning Brakes. The reel frame quickly installse with fasteners and non-rusting over center latches. The trailer is shown on concrete in front of a red metal building.

View of Sauber Mfg. Co. 15875 LED High Visibility Aluminum Light Bar from the side installed on the end of a pole.

Close image from right rear of a Sauber Model 4500 Pole Trailer's showing front fabricated bolster with 8840 Bronze Stanchions. The universal gear winch binders, 4" strap and pole hubs secure a wood utility pole to the trailer. It is daytime with the trailer on concrete in front of a red metal building.

Tight image of a bullnose hook and delta ring strap standard on a galvanized Model 1590 Telescoping Pipe Trailer.

Pole Trailer

Model 4500

Features & Benefits

Pole hauling is tough work, and your crews require equipment that delivers top-tier performance, ease of use, and long-lasting durability. The Model 4500 Pole Trailer is engineered to meet those demands with advanced features like a rugged nylon slide system, corrosion-free components, and an integrated aluminum light bar.

From the dual 10K EZ Up Jacks to the standard self-locking worm gear drive winches, every detail is designed to make the job safer and more efficient. This trailer is configurable for extended pole lengths and heavy weight capacities—work with us to tailor it to your specific needs.

With a standard hot-dipped galvanized finish, a protected wiring harness featuring a cat track tongue system, and durable bronze stanchions, the Model 4500 is built for reliable performance throughout its long service life.

Click here to see similar equipment.

Quick Specs

Capacity: 14730#
GVWR: 18750#
Retracted: 22'L x 90"W
Extended: 30'L x 90"W LR H

Request Pricing and Customization

Components
Sauber Standards

Pole Stanchions

Pole Hubs

Pole Trailer Cargo Bed

Rear Light Bar

Custom Reel Frame

SmartPerf Lined Tongue Area

Pole Muzzle

Winch Binder with Strap Choices

8805 Almag Outrigger Jack

Bent Mainframes

All-Weather Wheel Chocks

Wheel Nut Indicators

Warranty

Trailer Lighting Standards

Galvanizing

Safety Chains

Pole Stanchions

Galvanized stanchions for Pole Trailers provide a convenient way to position poles. Each is equipped with an over-center, variable tension, cam lock assembly. Because they are completely non-rusting, they won’t seize to the bolsters like old-fashioned stanchions do.

Pole Hubs

Dual pole hubs are standard on our Pole Trailers so operators can easily wrap the strap under the first binder hub, around the pole or poles, under the second binder hub and secure at the hook provided at the opposite end of the trailer. This method centrally secures the load without unsafe pole spreading.

Pole Trailer Cargo Bed

Enhance your Sauber Mfg. Co. Pole Trailer’s capability with a SmartPerf Cargo Bed. This galvanized material offers a flat surface with patterned slots that accept small binders and bungee hooks. This extra cargo space allows you to secure accessories or return spoil to your composting site back at the yard while leaving a finished worksite behind.

Right side three-quarter rear view of a Sauber Mfg. Co. Model 4410 Pole Trailer offering with galvanized finish, extendible tongue, All-Weather Wheel Chocks, and bronze stanchions. The trailer is shown on concrete in front of a red metal building.

Rear Light Bar

A rear lightbar is essential to communicate the length of your load and your intention to stop or turn. Our fluorescent orange powder coated aluminum light bar for Pole Trailers provides FMVSS 108 lighting at the rearmost pole position. It’s an integral part of the trailer, so it’s always there, ready and working. An exclusive Tread Grip lined “V” combined with a 2″ nylon ratchet binder provided on the light bar assures a firm hold on the pole. And note the optional flag holders and switched, 360-degree strobe. Best of all, it is lightweight and keeps your operators and equipment safe and legal. Please contact us if you’d like to make a purchase.

View of Sauber Mfg. Co. High Visibility Light Bar from the side installed on the end of a pole trailer.

Custom Reel Frame

We develop reel frame kits that retrofit to your existing flatbed truck or trailer. Bolt-on/off convenience creates a lot of flexibility for your fleet. Outfitting a custom frame with a turret assures the reel can line up to the work, not the whole vehicle. Our turrets lock on 6-degree intervals and rotate fully loaded with less than 10 pounds of force. A cost-effective alternative to a new trailer purchase. Contact us to discuss your application.

SmartPerf Lined Tongue Area

This smooth steel tongue area floor with a slot pattern offers drainage and a flat surface for material storage with attachment points for bungee or small straps.

Pole Muzzle

Available in several styles, galvanized pole muzzles provide a convenient method for connecting the lead pole to the towing vehicle. These units include safety chains and two methods for securing it to your wooden poles. Self-locking, worm drive winches with heavy duty 4″ straps are provided along with holes to allow attachment using customer provided crossarm bolts.

Benefits

Provides firm hold for utility poles
Includes safety chain for breakaway protection
Hot-dip galvanized finish survives real world field conditions
Best in class winch technology

Close view from above of the center frame area of a Sauber Mfg. Co. Pole Dinky. with galvanized finish and stainless-steel 8854 4-Watt Solar Battery Box. Centered in frame is an 8825-NG Stealth Pole Muzzle with 12,500 lbs. GVWR Rating including 3" Pintle Eye, Grade 70 safety chains and carry handles. The trailer is shown in the day on asphalt.

Winch Binder with Strap Choices

Ratchet-type binders are known as chin-busters and back-strainers for good reason. Finding that next tooth position to provide the right strength and torque is often frustrating and dangerous.

We offer self-locking, worm gear winch binders to eliminate a risk to safety with a 5500# capacity. They’re simple to use with the ability to hold tension at all times. With highly durable component materials and finishes, it is safer, easier to use and longer lasting than ratchet type binders. After thousands of installations in the field, they are tested and preferred by users across the U.S. and Canada. Our galvanized crank handle makes the operation smooth and simple. The 4″W nylon straps are color coded to identify length, for simple, correct replacement. Right-sized straps eliminate excessive strap tails after securement. Heavy duty hooks are installed opposite binders to secure the strap D-ring.

Care & Use

8805 Almag Outrigger Jack

Our standard Model 8805 Almag Outrigger Jack is the ultimate solution for durability and ease of use. With superior design and materials, you benefit from maintenance-free, rust-free service. Just move the bronze latch to raise or lower the jack leg, and you’re done. It’s that simple and reliable, ensuring you can focus on the day’s work without worrying about repairs or upkeep.

The Model 8805 Almag Outrigger Jack is standard on many of our utility construction trailers.

Daytime close view from above of a Sauber Mfg. Co. Trailer with Model 8805 Almag Outrigger Jack in the transport position. The trailer is shown on concrete in full sunshine.

Daytime close view of a Sauber Mfg. Co. Model 1519 Single Reel Turret Trailer with both Model 8805 Almag Outrigger Jacks in the deployed position. The trailer is shown in full sunshine on concrete in front of a red metal building.

Daytime close view from above of a Sauber Mfg. Co. Trailer with Model 8805 Almag Outrigger Jack in the deployed position. The trailer is shown on concrete in full sunshine.

Bent Mainframes

Why are bent frame tubes so important?

Look at the frames on vehicle chassis. You will find very little welding. Engineering a design with fewer welds provides structural benefits and is an intelligent thing to do.

Our Bent Structural Tube Trailer Frame has superior, uniform strength throughout the frame. A welded trailer A-frame has stress concentrations at the weld area’s heat-affected zone. A welded A-frame cannot possess the toughness inherent in a continuous, bent tube frame.

Inspection of this type of weld area is challenging because the joint is hidden by multiple weld passes. While this is common for many weld areas, this critical area presents unique challenges. Correct and repeatable steps are necessary. Both sides of the frame must have correctly executed, beveled angle cuts so that they join perfectly with no gaps. At the joint, the beveled surfaces must create a V-groove with the correct dimensions to allow weld penetration. Importantly, none of these aspects can be inspected after welding the joint, nor can the strength of the frame be verified. Additionally, the welded area has a discontinuous surface that is more susceptible to rust and deterioration over time, affecting the strength of the frame.

Our Bent Structural Tube Construction has none of these variables. It is stronger than a welded A-frame every time.

All-Weather Wheel Chocks

Specify Sauber Mfg. Co. All-Weather Wheel Chocks for safety. The grip strut face locks wheels tight on all surfaces in all weather conditions. The chock face grips tight to the tire surface while the motion of the tire wedges the chock between the wheel and the ground. The orange urethane grip handle is highly visible and reminds users to deploy and retrieve it. It is comfortable and easy to grip with gloved or bare hands.

All-Weather Wheel Chocks are unconditionally guaranteed against breakage for the life of the equipment they protect. Available with holders for every application, Sauber All-Weather Wheel Chocks continue to protect people and property decades after we designed and patented them.

Two Galvanized Steel Wheel Chock with grip strut surfaces leaning against one another. One chock has natural galvanized finish. The other chock is powder coated florescent orange. These chocks have an orange urethane grip handle.

One All-Weather Wheel Chock with steel grip strut surfaces in position on the ground against a tire. The wheel, mudflap and the wheel chock are visible. The All-Weather Wheel Chock has powder coat orange over galvanized finish and includes an orange urethane grip handle.

One All-Weather Wheel Chock with steel grip strut surfaces in position on the ground against a tire. Only the wheel and the wheel chock are visible. The All-Weather Wheel Chock has a natural galvanized finish and includes an orange urethane grip handle.

One All-Weather Wheel Chock with steel grip strut surfaces in position on the ground against the drive tire of a truck. Only part of the service body, the wheel and the wheel chock are visible. The All-Weather Wheel Chock has a natural galvanized finish and includes an orange urethane grip handle.

Almag wheel chock holder with Sauber Mfg. Co. All Weather Wheel Chock mounted to trailer fender. The trailer is a hot dipped galvanized Sauber Mfg. Co. Pole Trailer with dual wheels. The view is from the front of the wheels toward to the rear of the trailer. The the fender, one set of dual whees and the trailer rear are visible. Wheels are galvanized finished.

Sauber Mfg. Co. Model 8500-FO All Weather Wheel Chock with Orange Powder Coat Finish and 8501-R Almag Wheel Chock Holder mounted to trailer fender at an angle for easier access from the side.

View of the underbody of a Sauber Mfg. Co. Galvanized Platform Body with Model 8500-FO All Weather Wheel Chocks in powder coat orange finish over galvanizing secured in the Model 8505-B Almag Underbody Wheel Chock Holder.

Wheel Nut Indicators

During their daily safety check, your operator will be immediately aware of two potentially dangerous conditions with a quick look at our standard wheel nut indicators. The indicator may be pointing outside the circle pattern which will signal that a wheel nut has loosened. The indicator may also have started to blister and distort which indicates it has been exposed to temperatures above 240° which could be an indication of brake or bearing issues. A simple feature, but one that makes a Sauber trailer simpler and safer to operate.

Warranty

Sauber Manufacturing leads the field with a 10-year, comprehensive, trailer and truck platform warranty. This warranty comes at no charge to our customers and we have the financial strength and integrity to back it up. Our warranty is an extension of who we are and demonstrates the quality of our builds.

10-Year Structural, parts & labor on all Sauber manufactured components
10-Year Galvanized finish warranty
3-Year Total parts & labor coverage
3rd Party mechanized equipment like liftgates, cranes, and hoists are covered under their respective manufacturers’ warranties
Customer labor reimbursement @ $80/hour

Trailer Lighting Standards

We utilize an LED sealed beam/wiring system w/ stop/turn/tail lights recessed in fully enclosed tube bumper to meet FMVSS 108. Sealed wiring harnesses with no junction boxes or spliced connections. SAE 7-way socket protected top sides and back w/ Almag housing. 1100-52 sealed breakaway w/ charging circuit and LED battery condition indicator w/ 450 C.C.A. maintenance free battery. All trailers include our standard 12′ Coiled Jumper Cord w/ Zinc Die Cast 7-Way SAE Plugs.

For more detailed information, a link to NHTSA can be found here.

Front view of a Sauber Mfg. Co. Model 1539 Three Reel Turret Trailer showing the pintle eye and part of the a-frame including pintle, extension, coil jumper cord, hitch plate, tubing frame, socket housing, breakaway switch / housing, SmartPower Box 12VDC Power Source, and 10K EZ Up Jack Assembly.

Galvanizing

Hot dipped galvanized finish is standard across our entire line of trailers.

Experience counts and you can count on weldments and equipment designs which optimize the benefits of hot dipped galvanizing. We include bolt-on cargo decking that is flat and safe to walk on. In addition, we provide accessories in hot dipped galvanized whenever feasible. Often, we’ll provide axle components in galvanized finish. In fact, all our trailer wheels are galvanized as well.

Every day, customers trust our experience in galvanizing, innovative features, and durable design to work with them on their next successful trailer application.

Comparison of metalizing vs Hot Dip Galvanizing

Galvanized Metal Repair

Galvanizing Technical

Safety Chains

Chain traps secure the safety chain at two links for ultimate holding power. Our unique method of installation doesn’t require connecting links or welding of the chain, compromising its integrity. Chain traps and complete Grade 70 chain and Grade 70 Hook assemblies are available.

Safety Chain & Drawbar Guidelines
